SJV-750

  • 0.750X1.37X40WL.875J2V-TYD
$65.10
In-stock
This product fits [] different pump model(s)
See detailed list

Product overview

Service Application:
Chemical
Shaft Size:
.750
Head Elastomer:
Viton
Washer Material:
Carbon
Head Type:
D Head
Head Od:
1.437
Operating Height:
.875
Seat Type:
O-Ring Mount
Seat Material:
Ceramic
Seat Od:
1.375
Seat Thickness:
.406
Material:
Viton Rubber
Made in USA:
Y

U.S. Seal||PS-750V||~ Armstrong Pump||816707-003||~ Armstrong Pump|| ||Serial #6505 & Later||S69 Size 6 AB/STD/BF~ Armstrong Pump|| ||Serial #6505 & Later||H63 Size 6 AB/STD/BF~ Armstrong Pump|| ||Serial #6505 & Later||H64 Size 6 AB/STD/BF~ Armstrong Pump|| ||Serial #6505 & Later||H65 Size 6 AB/STD/BF~ Armstrong Pump|| ||Serial #6505 & Later||H66 Size 6 AB/STD/BF~ Armstrong Pump|| ||Serial #6505 & Later||H67 Size 6 AB/STD/BF~ Armstrong Pump|| ||Serial #6505 & Later||H68 Size 6 AB/STD/BF~ Armstrong Pump|| ||Serial #6505 & Later||1060 1-1/2D Size 6 AB/STD/BF~ Armstrong Pump|| ||Serial #6505 & Later||1060 2D Size 6 AB/STD/BF~ Armstrong Pump|| ||Serial #6910 & Later||1060 3D Size 6 AB/STD/BF~ EIS||PUMUS750V||

SJV-750

fits these pumps
Manufacturer
Part Number
Model Number
Series
U.S. Seal
PS-750V


Armstrong Pump
816707-003


Armstrong Pump

Serial #6505 & Later
S69 Size 6 AB/STD/BF
Armstrong Pump

Serial #6505 & Later
H63 Size 6 AB/STD/BF
Armstrong Pump

Serial #6505 & Later
H64 Size 6 AB/STD/BF
Armstrong Pump

Serial #6505 & Later
H65 Size 6 AB/STD/BF
Armstrong Pump

Serial #6505 & Later
H66 Size 6 AB/STD/BF
Armstrong Pump

Serial #6505 & Later
H67 Size 6 AB/STD/BF
Armstrong Pump

Serial #6505 & Later
H68 Size 6 AB/STD/BF
Armstrong Pump

Serial #6505 & Later
1060 1-1/2D Size 6 AB/STD/BF
Armstrong Pump

Serial #6505 & Later
1060 2D Size 6 AB/STD/BF
Armstrong Pump

Serial #6910 & Later
1060 3D Size 6 AB/STD/BF
EIS
PUMUS750V



*with exception of U.S. Seal, all manufacturer's names, part numbers, and descriptions are used for reference purposes only. It is not implied that any part is the product of these manufacturers.ca-prop-65.png
